Caterpillar C32 Marine Diesel Engine Heat Exchanger Plates, Gaskets & Seals
Precision-engineered heat exchanger components for CAT C32 marine propulsion engines—OEM-quality performance, corrosion resistance, and global delivery.
Caterpillar C32 Heat Exchanger Gaskets, Plates & Seals
The Caterpillar C32 marine diesel engine is a 12-cylinder, 32.1-liter powerhouse delivering up to 1,800+ horsepower, with certain C32B models exceeding 2,000 HP. Built for demanding continuous-duty applications, the C32 powers luxury yachts, sportfishing vessels, offshore supply boats, and commercial workboats requiring exceptional reliability and performance.
At the core of the C32’s cooling system is its titanium or stainless steel plate-type heat exchanger, which uses raw seawater to regulate engine temperature. This closed-loop system keeps the internal coolant isolated from seawater—transferring heat efficiently while protecting critical engine components from corrosion and fouling.
MechPro supplies complete C32 heat exchanger gasket kits, plate packs, bolts, spacers, seals, and replacement components compatible with all major C32 variants, including C32 ACERT and C32B. Every component meets or exceeds OEM quality standards to ensure long service life in harsh marine environments.
To Schedule Parts & Service Today
Call 1 (800) 249-6709 or Use our RFQ Form
C32 heat exchanger shipped to MechPro for inspection and cleaning.
CAT C32 heat exchanger on-site inspection services by MechPro.
CAT C-32 marine heat exchanger shipped to MechPro for routine scheduled maintenance.
CAT C-32 heat exchanger plates in refurbished unit.
CAT C-32 marine heat exchanger OEM quality parts.
Why Choose MechPro
- Worldwide Shipping – Fast and reliable delivery of all Cat® marine heat exchanger parts.
- Genuine & Aftermarket Options – OEM-spec compression, heat tolerance, and installation compatibility.
- Expert Support – Send us your serial number, part code, or image for instant identification help.
- Trusted Supplier – Over 15 years of heat exchanger service expertise across marine, refinery, and power generation industries.
Precision-Engineered for Reliability
Long-term durability, high fuel efficiency, simplified service, and long-life-to-overhaul — Cat® marine engines are designed for maximum productivity and minimal downtime.
A consistent maintenance schedule extends your Caterpillar engine’s lifespan and performance.
MechPro supports that mission by providing exact-fit heat exchanger components built to OEM specifications.
MechPro supplies CAT C-32 heat exchanger parts and service.
Refurbished CAT C32 heat exchanger plates and gaskets.
MechPro services CAT C-32 marine diesel engine heat exchangers coast to coast.
To Schedule Parts & Service Today
Call 1 (800) 249-6709 or Use our RFQ Form
Caterpillar C32 Heat Exchanger Parts List
(Representative components; verify by engine serial prefix or arrangement number. Contact MechPro for confirmation.)
| Part Name | Caterpillar Part Number (Example) | Description |
|---|---|---|
| Plate – Heat Exchanger | 358-7056, 358-7063, 358-7071 | Titanium or stainless plate, corrugated design |
| Gasket – Plate | 7E-4642, 6N-4083, 4N-7825 | Rubber seal gasket, coolant isolation |
| Seal – O-Ring | 1P-3706, 8M-4991, 9X-8258 | O-ring for end cover and tube seals |
| Spacer – Plate Pack | 8N-9680, 9M-9801 | Spacer ring for plate alignment |
| Bolt – Assembly | 5M-2904, 7X-0840, 8S-3223 | High-tensile stainless fasteners |
| Collar – Locating | 1N-3802, 3B-4512 | Alignment collar between plate sets |
| End Cover – Housing | 6I-4356, 9N-9845 | Heat exchanger end cover assembly |
| Gasket Kit – Complete | SEBP5243-022, SEBP5243-028 | Full C32 marine heat exchanger gasket kit |
| Liner – Coolant Tube | 327-1099, 327-1105 | Protective liner for coolant circuits |
Refer to Caterpillar Service Publication SEBP5243 (Marine C32 Heat Exchanger Assembly) or request MechPro’s labeled parts scheme for your model.
Product Overview
Heat Exchanger Gaskets
Create a tight, leak-free seal between exchanger plates. Essential for efficient operation and fluid isolation.
Heat Exchanger Plates
Precision-engineered titanium plates maximize heat transfer efficiency, ensuring consistent cooling for C30 engines.
Heat Exchanger Seals
Durable elastomeric seals prevent leaks at joints and maintain proper pressure within the system.
Together, these components sustain optimal engine cooling performance, prevent overheating, and extend engine life.
Maintenance Recommendations
Routine maintenance of your C32 cooling system ensures optimal temperature regulation and engine longevity:
Inspect and clean plate stack every 1,000 hours or annually
Replace gaskets during each teardown to prevent leaks
Flush seawater system with freshwater after extended operation
Check raw water pump impeller for wear or blockage
Monitor coolant levels and maintain correct inhibitor concentration
Caterpillar C32 Marine Engine Specifications
| Specification | Details |
|---|---|
| Configuration | V-12, 4-stroke-cycle diesel |
| Displacement | 32.1 L (1959 in³) |
| Bore × Stroke | 145 mm × 162 mm (5.7 in × 6.38 in) |
| Aspiration | Twin-turbocharged, aftercooled (air-to-air or seawater) |
| Power Range | 800–1,900+ bhp (597–1,417 kW) |
| Rated Speed | 1,600–1,800 rpm (varies by rating) |
| Governor | Electronic (ADEM A5 ECM) |
| Rotation (flywheel end) | Counterclockwise |
| Cooling System | Heat Exchanger or Keel-Cooled |
| Emissions | EPA Tier 4 Final / IMO III certified (with SCR) |
| Dry Weight | 6,950–7,160 lb (3,152–3,248 kg) |
| Dimensions (L×W×H) | 77.8–83.5″ × 60.2″ × 60.9–62.5″ |
Request a Quote
Need verified replacement parts for your C32 heat exchanger?
Send us your engine serial number or a photo of your heat exchanger assembly, and our team will confirm the correct part numbers and deliver a fast quote.
📞 Call: 1 800 249-6709
📧 Email: [email protected]
Or simply use our Request for Quote form to send us your engine model and photos of the exchanger — we’ll handle the rest.
Frequently Asked Questions (FAQs)
Q: What are typical marine applications for the CAT C32?
A: The C32 is used in luxury yachts, sportfishing vessels, offshore supply vessels, commercial trawlers, and patrol boats, providing high power with proven reliability.
Q: How often should heat exchanger plates and gaskets be replaced?
A: Plates should be cleaned and inspected every 1,000 operating hours; gaskets must be replaced at every disassembly to maintain sealing integrity.
Q: Are MechPro parts compatible with C32 ACERT and C32B engines?
A: Yes—MechPro supplies plate and gasket kits for all C32 variants. Provide your engine serial number (ESN) for an exact match.
Q: Do most CAT C32 engines use shell and tube or plate and frame heat exchangers?
A: Most CAT C32 engines use either a shell-and-tube or a plate heat exchanger, depending on the specific application and configuration. Marine versions of the C32 often use a plate-type heat exchanger for efficiency in a closed-loop seawater cooling system, while some industrial and generator sets may use a shell-and-tube design for the jacket water cooling circuit, as seen in certain generator set configurations.
Plate heat exchangers
- Used in: Most frequently seen in marine applications.
- How it works: Uses raw seawater to cool internal engine coolant in a closed-loop system, which keeps engine components from corroding or fouling from seawater.
- Advantages: More compact and can be more efficient than shell-and-tube designs in specific applications.
Shell and tube heat exchangers
- Used in: Some configurations, particularly for the jacket water cooling circuit in certain marine generator sets.
- How it works: A bundle of tubes is housed inside a cylindrical shell, with coolant flowing through the tubes and a separate fluid flowing around them in the shell.
- Advantages: Can be more robust in very harsh environments and easier to clean and repair in some cases.
Disclaimer
All manufacturer names, part numbers, and product descriptions are provided for reference and identification purposes only. Caterpillar®, CAT®, and associated model names and numbers are registered trademarks of Caterpillar Inc.
MechPro is not an authorized dealer for Caterpillar Inc. and is not affiliated with the company. Our inventory is constantly changing and may include both genuine OEM parts and high-quality aftermarket replacements. Unless explicitly stated, we do not guarantee that a listed item is manufactured by the original equipment manufacturer.
Product images, diagrams, and specifications are for reference only and may not exactly match the item shipped. Customers should use original part numbers to verify compatibility and determine the most suitable replacement for their needs.
